Compact High-Power UV Flood Curing System
The SunRay is a compact and high-performance UV flood curing system designed for efficient and reliable operation. Its integrated lamp head design simplifies installation by reducing wiring and eliminating the need for additional control units. Available with 400W or 600W metal halide lamps, the system delivers uniform UV output across an 8 × 6 inch curing area. A built-in handle and adjustable sliding bracket improve portability and positioning flexibility. The system provides consistent curing performance, making it suitable for a wide range of industrial curing applications.
Key Features
Auto-Range AC Input
The system automatically detects and adjusts to different input voltages, reducing installation complexity and preventing incorrect voltage selection.
Stable Lamp Power Regulation
An advanced power supply maintains consistent lamp output regardless of voltage fluctuations, ensuring repeatable curing results and extending lamp life.
Energy-Saving Standby Mode
A simple standby function reduces lamp power when the system is idle, minimizing heat generation, energy consumption, and stray UV exposure.
Operating Hour Meter
A built-in hour meter tracks lamp usage, helping users monitor lamp life and schedule maintenance more effectively.
Forced Air Cooling
An efficient fan-assisted cooling system dissipates heat from critical components, ensuring stable operation, improved reliability, and extended equipment life.
Key Specification
Parameter | Value |
System Type | Parabolic Flood Curing System |
Part # | UV0446; UV0830 |
Lamp Power | 400W; 600W |
Input Voltage | 100-120 / 200-240 AC ±10% (Auto-ranging) |
Input Current (Max @ 120/240V) | 7.0A/3.5A; 10.0A/5.0A |
Typical UV Irradiance at 3″ | 115 mW/cm²; 175 mW/cm² |
Curing Area | 8 × 6 in |
Weight | 11 lbs |
Size (L × W × H) | 11 × 10 × 9 in |
×
