UV Conveyor 40 Plus
UV Conveyor 40 Plus – Dual-Lamp UV Curing Conveyor
The UV Conveyor 40 Plus is a versatile dual-lamp UV curing conveyor designed for laboratory and production environments. It features a quiet, variable-speed motor that delivers stable and consistent belt movement for reliable curing performance. Adjustable lamp height and removable lamp heads provide flexibility for different part sizes and applications. Compatible with SunRay UV arc lamps, SkyRay UV LED systems, and additional side-cure PortaRay arc lamps, the system can be configured for full UV coverage. Comprehensive UV shielding and customizable options make it suitable for a wide variety of curing applications.
Key Features
Adjustable Lamp Height
Foldaway access hoods allow quick access to lamp height adjustment pins, ensuring accurate and repeatable lamp-to-belt positioning.
Adjustable End Chute
The adjustable end chute helps collect cured parts efficiently as they exit the conveyor.
Complete UV Shielding
The fully enclosed curing chamber protects operators and nearby personnel from UV exposure. Tinted acrylic entry and exit doors provide additional protection.
Digital Speed Display & Emergency Stop
A digital display shows conveyor belt speed in real time, while the emergency stop button enables quick and safe shutdown of the conveyor and lamps.
Removable Lamp Heads
Lamp heads can be easily removed for maintenance, bulb replacement, or offline testing using optional mounting stands and curing chambers.
Dual Spectrum Capability
Supports combining different lamp spectrums within a dual-lamp configuration to optimize both surface curing and deeper curing applications.
Key Specification
| Parameter | Value |
| System Type | Dual-lamp, variable-speed UV Curing Conveyor |
| Part # | UV3028-120M (120 VAC); UV3028-240M (240 VAC, required for dual SkyRay 800) |
| Input Voltage | 100-120 / 200-240 VAC ±10% |
| Input Current (Max @ 120/240V) | 20A at 120V; 15A at 240V |
| Curing Width | 6 in exposure width; 9 in max part width |
| Belt (L × W) | 54 × 9 in |
| Belt Speed | 0.5-25 ft/min |
| Lamp Height (Adjustable) | 1.2-6.7 in, 0.5 in steps |
| Size (L × W × H) | 54 × 14 × 16 in |
| Weight | 63.2 lbs |
×
