H&M 502 Single Station Low Pressure Molding Machine
Designed for product coating using various low-pressure molding hot-melt adhesive resins. It serves as a rapid-prototyping replacement for pouring sealant with shells, providing insulation and waterproofing.
Working Pressure: 0 to 6 MPa (safe for delicate components, no chemical reaction).
Common Industry Uses: Automotive electronics, automotive wiring harnesses, coaxial cables, waterproof connectors, LED modules/lamps, PCBA, sensors, coils, flexible circuit boards, polymer batteries, smart home devices, and wearable electronics.
Key Features
Injection System
Equipped with a super-hard gear pump and glue guns for a compact structure, stable injection, and long service life.
Configuration
Double position and double horizontal glue gun layout, offering extra space for complex molds.
Control
Injection pressure is completely adjustable via the main control panel.
Layout
Workstation and melt system feature a flexible "fission" (modular/separated) layout.
Temperature Regulation
Utilizes three separate temperature controllers for precise management of system components (glue gun, heated hose, melt tank).
Mold Management
Standardized mold design for easy changeouts; features a built-in product ejection device for easy removal.
Options
Optional double glue cylinder upgrades for enhanced injection stability and higher production efficiency.
Key Specification
| Machine Size | 1080mm × 720mm × 1890mm (446Kgs) |
| Packing Size | 1280mm × 920mm × 2000mm (496Kgs) |
| Work Station Height | 1030mm |
| Melting Tank Model & Qty | KH05 (5Liter) × 1PC |
| Nozzle & Tip Angle | KG40 × 2PC (60° ) [Note: Page 1 lists KG40×1PC 36°] |
| Heated Hose Model & Qty | KJ16 × 2PC [Note: Page 1 lists KJ16×1PC] |
| Electricity | 220VAC / 1Phase / 50 or 60Hz |
| Temperature Control Zones | 5 |
| Temperature Range Ambient | up to 280°C |
| Max. Power | 4.5Kw |
| Min. Air Pressure | 0.5Mpa |
| Air Consumption | 0.1m³/min |
| Clamping Device | Cylinder |
| Clamping Force | Max. 1.2Ton |
| Clamping Stroke (mm) | 150mm |
| Control System | PLC + 7″ HMI |
| LPIM Standard Mold Set Size (mm) | 190 × 130 × 150 |
| Max. Mold Set Size (mm) | 300 × 200 × 150 |
×
